1TB Recorder


16 : 22/HT620/S/16C/2T
8 : 22/HT620/S/8C/1T

: max 8 TB HDD

NasCam NVR recorders are above all:

  • Comprehensive video data protection
  • Lifetime Update
  • Enhanced cybersecurity
  • Reliable LINUX
  • User-friendly interface
  • Flexible access from PCs or mobile devices
  • Fast connection to front-end devices

Ask for availability
Blog Image
Blog Image
Blog Image
Blog Image
Blog Image

NASCAM DEMO

We invite you to test our system. The demo is a network version and does not include all functions of a desktop recorder.

NASCAM NVR DEMO PANEL

login: demo@nascam.pl
password: demonascam

Product Detail

The 16-channel IP recorder enables the operation of monitoring systems based on 16 IP cameras with a resolution of up to 8 MP. The device can save the recorded image on a SATA disk with a capacity of up to 8TB. The recorder does not require the installation of additional plugins. Management is done via a web browser. The 16-channel IP recorder enables operation of monitoring systems based on up to 16 IP cameras with a maximum resolution of 8 MP. The device can save the recorded image on a SATA disk with a capacity of up to 8TB.

The recorder can be operated in many ways via a web browser, telephone, tablet or by connecting a monitor. Importantly, the recorder does not require the installation of additional plug-ins to play video streams and real-time playback of camera images.

The recorder enables:


NasCam recorders are equipped with AUTODISCOVER functions. The cameras are detected automatically, which greatly facilitates the installation process. It is also possible to provide a direct link to the stream in case of problems with camera detection.

The system has many additional tools to facilitate, among others, the location of cameras, diagnosing faults. The whole system is complemented by a mobile application that allows you to view the device and recordings.

The recorder will be used in surveillance systems:


NasCam supports many leading manufacturers of network cameras, including Axis, Hikvision, Vivotek, ACTi, Dahua, supports the ONVIF standard. The entire system is located on a device adapted to continuous operation, which guarantees the continuity of operation for many years.

SPECIFICATION


Camera input Max 16 channels
Video output HDMI/VGA output resolution
Decoding format H.264+/H.264/H.265
Supported resolutions 64 @ 4000 x 3000 px,
64 @ 3840 x 2160 px,
64 @ 3072 x 2048 px,
64 @ 2592 x 1944 px,
64 @ 2560 x 1440 px,
64 @ 2048 x 1536 px,
64 @ 1920 x 1080 px,
64 @ 1280 x 720 px,
64 @ 704 x 576 px
Network protocols HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, VPN, DDNS, FTP ONVIF 2.4
Hard disk 1 SATA interface
Power 65 W worldwide auto-sensing, 100-240 V AC, 50-60 Hz energy-saving automatic power-down, surge-tolerant
Ports 2 x USB 3.0
6 x USB 2.0 (4x external, 2x internal)
1 x 1/8" (3.5 mm) headphone jack
1 x 1/8" (3.5 mm) mic-in jack
1 x audio-in jack
1 x RJ-45
2 x PS/2
2 x DisplayPort 1.2
Weight 3.00 lb / 1.36 kg
Mouse support YES
Keyboard support YES
Login Credentials admin/Nascam1234
